Ford · 2021–2026
Mustang Mach-E Select RWD
Electric SUV with Mustang DNA. Here's what its onboard charger actually needs from your home's electrical panel.
Home (Level 2) charging facts
Pulled straight from the Mustang Mach-E Select RWD's onboard charger rating - not a generic EV number.
- Onboard charger draw
- 10.5 kW
- ~44A at 240V (kW × 1000 ÷ 240)
- Empty-to-full at max Level 2
- 6.9 hrs
- 72 kWh battery ÷ 10.5 kW
- Range added per hour
- ~37 mi/hr
- 10.5 kW × 3.5 mi/kWh efficiency
- DC fast charging
- 115 kW max
- Public chargers only - tapers as the battery fills
Typical full-speed install
48A charger on a 60A circuit
Reaches this car's 10.5 kW ceiling. Whether your panel has room for that circuit depends on everything else already on it - that's the actual assessment.
Connector
CCS
CCS (Combined Charging System) is the most common connector on non-Tesla EVs for both home Level 2 charging and public DC fast charging.
On the Mustang Mach-E Select RWD specifically, that connector carries up to 10.5 kW at home on Level 2 and up to 115 kW on public DC fast hardware.
Charging speed by circuit size
The Ford Mustang Mach-E's onboard charger can't use more than 10.5 kW AC no matter how big the circuit - past 48A, a bigger charger buys you nothing on this car.
| Charger setting | This car actually draws | Range added / hour | 8-hr overnight |
|---|---|---|---|
| 16A | 3.8 kW | ~13 mi | ~104 mi |
| 24A | 5.8 kW | ~20 mi | ~160 mi |
| 32A | 7.7 kW | ~27 mi | ~216 mi |
| 40A | 9.6 kW | ~34 mi | ~272 mi |
| 48A | 10.5 kWcapped by car | ~37 mi | ~296 mi |
Overnight, at full onboard speed
296 mi / 8 hrs
370 mi across a 10-hour window, at 10.5 kW.
Approximate cost to fill from empty
$9.36
Assumes $0.13/kWh (a national-average estimate, not your local rate) × 72 kWh - about $0.037/mile.
Ford Mustang Mach-E charging questions
How long does it take to charge a 2021–2026 Ford Mustang Mach-E Select RWD on a Level 2 charger?
About 6.9 hours from empty to full at its 10.5 kW onboard-charger ceiling (72 kWh battery ÷ 10.5 kW).
Times scale with amperage - see the circuit-size table above for other settings.
What amperage does a Ford Mustang Mach-E draw on Level 2?
At its full 10.5 kW rate, the Ford Mustang Mach-E draws about 44A at 240V (kW × 1000 ÷ 240 = amps).
Can a Ford Mustang Mach-E use a 48-amp charger?
Not to any real benefit. The Ford Mustang Mach-E's onboard charger tops out at 10.5 kW (~44A) - a 48A charger doesn't charge it any faster than one already sized to 44A.
How much range does a Ford Mustang Mach-E add per hour on a Level 2 charger?
About 37 miles of range per hour at its 10.5 kW ceiling (10.5 kW × 3.5 mi/kWh efficiency).
How much range does an 8-hour overnight charge add to a Ford Mustang Mach-E?
Roughly 296 miles from an 8-hour overnight charge (37 mi/hr × 8 hours), or about 370 miles across a 10-hour window.
What's the DC fast charging ceiling for a Ford Mustang Mach-E?
Up to 115 kW on a public DC fast charger - well above its 10.5 kW Level 2 (home) ceiling, though DC fast rates taper as the battery fills.
