Cadillac · 2025–2026
Escalade IQ Luxury
Full-size electric luxury SUV with massive 200kWh battery. Standard 11.5kW charger. Here's what its onboard charger actually needs from your home's electrical panel.
Home (Level 2) charging facts
Pulled straight from the Escalade IQ Luxury's onboard charger rating - not a generic EV number.
- Onboard charger draw
- 11.5 kW
- ~48A at 240V (kW × 1000 ÷ 240)
- Empty-to-full at max Level 2
- 17.4 hrs
- 200 kWh battery ÷ 11.5 kW
- Range added per hour
- ~25 mi/hr
- 11.5 kW × 2.15 mi/kWh efficiency
- DC fast charging
- 350 kW max
- Public chargers only - tapers as the battery fills
Typical full-speed install
48A charger on a 60A circuit
Reaches this car's 11.5 kW ceiling. Whether your panel has room for that circuit depends on everything else already on it - that's the actual assessment.
Connector
NACS
NACS (North American Charging Standard, originally Tesla's plug) is now the connector most new EVs are shipping with for both home Level 2 and public DC fast charging.
On the Escalade IQ Luxury specifically, that connector carries up to 11.5 kW at home on Level 2 and up to 350 kW on public DC fast hardware.
Charging speed by circuit size
The Cadillac Escalade IQ's onboard charger can't use more than 11.5 kW AC no matter how big the circuit - past 48A, a bigger charger buys you nothing on this car.
| Charger setting | This car actually draws | Range added / hour | 8-hr overnight |
|---|---|---|---|
| 16A | 3.8 kW | ~8 mi | ~64 mi |
| 24A | 5.8 kW | ~12 mi | ~96 mi |
| 32A | 7.7 kW | ~17 mi | ~136 mi |
| 40A | 9.6 kW | ~21 mi | ~168 mi |
| 48A | 11.5 kWcapped by car | ~25 mi | ~200 mi |
Overnight, at full onboard speed
200 mi / 8 hrs
250 mi across a 10-hour window, at 11.5 kW.
Approximate cost to fill from empty
$26.00
Assumes $0.13/kWh (a national-average estimate, not your local rate) × 200 kWh - about $0.060/mile.
Cadillac Escalade IQ charging questions
How long does it take to charge a 2025–2026 Cadillac Escalade IQ Luxury on a Level 2 charger?
About 17.4 hours from empty to full at its 11.5 kW onboard-charger ceiling (200 kWh battery ÷ 11.5 kW).
Times scale with amperage - see the circuit-size table above for other settings.
What amperage does a Cadillac Escalade IQ draw on Level 2?
At its full 11.5 kW rate, the Cadillac Escalade IQ draws about 48A at 240V (kW × 1000 ÷ 240 = amps).
Can a Cadillac Escalade IQ use a 48-amp charger?
Not to any real benefit. The Cadillac Escalade IQ's onboard charger tops out at 11.5 kW (~48A) - a 48A charger doesn't charge it any faster than one already sized to 48A.
How much range does a Cadillac Escalade IQ add per hour on a Level 2 charger?
About 25 miles of range per hour at its 11.5 kW ceiling (11.5 kW × 2.15 mi/kWh efficiency).
How much range does an 8-hour overnight charge add to a Cadillac Escalade IQ?
Roughly 200 miles from an 8-hour overnight charge (25 mi/hr × 8 hours), or about 250 miles across a 10-hour window.
What's the DC fast charging ceiling for a Cadillac Escalade IQ?
Up to 350 kW on a public DC fast charger - well above its 11.5 kW Level 2 (home) ceiling, though DC fast rates taper as the battery fills.
