Fiat · 2024–2026
500e Inspired By
Retro-styled city EV. 11kW onboard charger — full charge in about 4 hours on Level 2. Here's what its onboard charger actually needs from your home's electrical panel.
Home (Level 2) charging facts
Pulled straight from the 500e Inspired By's onboard charger rating - not a generic EV number.
- Onboard charger draw
- 11 kW
- ~46A at 240V (kW × 1000 ÷ 240)
- Empty-to-full at max Level 2
- 3.8 hrs
- 42 kWh battery ÷ 11 kW
- Range added per hour
- ~38 mi/hr
- 11 kW × 3.43 mi/kWh efficiency
- DC fast charging
- 85 kW max
- Public chargers only - tapers as the battery fills
Typical full-speed install
48A charger on a 60A circuit
Reaches this car's 11 kW ceiling. Whether your panel has room for that circuit depends on everything else already on it - that's the actual assessment.
Connector
CCS
CCS (Combined Charging System) is the most common connector on non-Tesla EVs for both home Level 2 charging and public DC fast charging.
On the 500e Inspired By specifically, that connector carries up to 11 kW at home on Level 2 and up to 85 kW on public DC fast hardware.
Charging speed by circuit size
The Fiat 500e's onboard charger can't use more than 11 kW AC no matter how big the circuit - past 48A, a bigger charger buys you nothing on this car.
| Charger setting | This car actually draws | Range added / hour | 8-hr overnight |
|---|---|---|---|
| 16A | 3.8 kW | ~13 mi | ~104 mi |
| 24A | 5.8 kW | ~20 mi | ~160 mi |
| 32A | 7.7 kW | ~26 mi | ~208 mi |
| 40A | 9.6 kW | ~33 mi | ~264 mi |
| 48A | 11.0 kWcapped by car | ~38 mi | ~304 mi |
Overnight, at full onboard speed
304 mi / 8 hrs
380 mi across a 10-hour window, at 11 kW.
Approximate cost to fill from empty
$5.46
Assumes $0.13/kWh (a national-average estimate, not your local rate) × 42 kWh - about $0.038/mile.
Fiat 500e charging questions
How long does it take to charge a 2024–2026 Fiat 500e Inspired By on a Level 2 charger?
About 3.8 hours from empty to full at its 11 kW onboard-charger ceiling (42 kWh battery ÷ 11 kW).
Times scale with amperage - see the circuit-size table above for other settings.
What amperage does a Fiat 500e draw on Level 2?
At its full 11 kW rate, the Fiat 500e draws about 46A at 240V (kW × 1000 ÷ 240 = amps).
Can a Fiat 500e use a 48-amp charger?
Not to any real benefit. The Fiat 500e's onboard charger tops out at 11 kW (~46A) - a 48A charger doesn't charge it any faster than one already sized to 46A.
How much range does a Fiat 500e add per hour on a Level 2 charger?
About 38 miles of range per hour at its 11 kW ceiling (11 kW × 3.43 mi/kWh efficiency).
How much range does an 8-hour overnight charge add to a Fiat 500e?
Roughly 304 miles from an 8-hour overnight charge (38 mi/hr × 8 hours), or about 380 miles across a 10-hour window.
What's the DC fast charging ceiling for a Fiat 500e?
Up to 85 kW on a public DC fast charger - well above its 11 kW Level 2 (home) ceiling, though DC fast rates taper as the battery fills.
